Schlage Elan Satin Nickel Light Commercial Keyed Entry Door Lever
Elan Keyed Entry Door Lever
The Schlage Elan keyed entry lever delivers light commercial-grade security with everyday convenience. Built from premium metal and certified Grade 2/AAA, it fits standard doors and installs easily with a screwdriver.
Key Features:
- Light Commercial Security: ANSI/BHMA Grade 2 with AAA rating for security, durability and finish
- Easy Installation: Self-aligning screw holes and universal latch for 2-3/8 in. or 2-3/4 in. backsets
- Versatile Fit: Works with 1-3/8 in. to 1-3/4 in. door thickness; includes radius and drive-in faceplates
- Convenient Operation: Keyed exterior with interior turn-button; unlocks by rotating handle from inside for quick exit
- Durable Build & Warranty: Premium metal construction with limited lifetime mechanical and finish warranty
Specifications Table:
| Specification | Details |
|---|---|
| Lever Style | Elan |
| Function | Keyed entry (keyed exterior; interior turn-button; unlocks by rotating handle from inside) |
| Backset | Adjusts to 2-3/8 in. (60 mm) or 2-3/4 in. (70 mm) |
| Door Thickness | 1-3/8 in. (35 mm) to 1-3/4 in. (44 mm) |
| Keying | 5-pin tumbler, C keyway standard |
| Handing | Right and left handed doors |
| Material | Premium metal construction |
| Certifications | ANSI/BHMA A156.39-2015 Grade AAA (Security, Durability, Finish); ANSI/BHMA A156.2 2011 Grade 2 |
| UL Listed | Locks for up to three-hour fire doors available |
| Warranty | Limited Lifetime Mechanical and Finish Warranty |
| Included Components | Lockset, universal latch, radius and drive-in faceplates, strike, mounting hardware, 2 keys |
Frequently Asked Questions (FAQ):
Q: What doors will this lever fit?
A: It fits standard doors 1-3/8 in. to 1-3/4 in. thick with 2-3/8 in. or 2-3/4 in. backsets.
Q: Is it reversible for left- or right-handed doors?
A: Yes, it is designed for both right and left handed doors.
Q: What keying does it use?
A: It uses a 5‑pin tumbler with C keyway standard and includes two keys.
Q: Is it fire-rated?
A: Models for up to three-hour fire doors are available; check your specific variant’s rating.
Q: Does it include everything needed for installation?
A: Yes, the lockset includes latch, strike, faceplates, mounting hardware, and two keys; only a screwdriver is needed.
Sleek Modern Security with Streamlined Confidence
Elan’s crisp linear lever brings a tailored, architectural note to any entry, balancing minimalism with presence. The streamlined silhouette feels refined yet substantial in hand, creating a polished moment on the door. Pair it with flat-front cabinetry and matte hardware for contrast, or echo its geometry with clean-lined lighting. It’s a quiet luxury essential—where style meets steadfast performance.
Secure your entry with the Schlage Elan—upgrade today for reliable performance and effortless style.
